Chapter 18 Store and Load RIGOL
MSO5000 User Guide 18-23
Signal
CAN_L
Baud
1 Mbps
Sample Position
50%
FlexRay
Bus Status
OFF
Source
CH1
Threshold
0 V
Channel
Selection
A
Baud
10 Mbps
Signal
BP
Sample Position
50%
I2S
Bus Status
OFF
SCLK
CH1
SCLK Thre
0 V
SCLK Edge
Rising
WS
CH2
SCLK Thre
0 V
Data
CH3
Data Thre
0 V
Word Size
4
Receive
4
Alignment
I2S
WS Low
Left
Endian
MSB
Data Polarity
1553B
Bus Status
OFF
Data
CH1
Threshold
0 V
Ref
Current
Ref1
Source
CH1
VScale
1 V
VOffset
0 V
Color
Orange
Label Display
OFF
Library
Default
Label
REF1
Note
[1]
: It is only available for the model installed with the MSO5000-AWG option.
Note
[2]
: PLA2216 active logic probe option is required to be ordered.
