Chapter 20 System Utility Function Setting RIGOL
MSO5000 User Guide 20-3
⚫ Invalid IP!
⚫ IP lost!
⚫ Please wait...
IP Configuration Type
The configuration type of the IP address can be DHCP, Auto IP, or Static IP. For
different IP configuration types, the configurations for IP address and other network
parameters are different.
DHCP
Press IP Config Type, then rotate the multi-function knob or press IP Config
Type continuously to select "DHCP". Press down the knob to select it. You can
also enable the touch screen to select it. When DHPC is valid, the DHCP server in the
current network will assign the network parameters (e.g. IP address, Subnet,
Gateway, and DNS) for the oscilloscope.
Auto IP
Press IP Config Type, then rotate the multi-function knob or press IP Config
Type continuously to select "Auto IP". Press down the knob to select it. You can
also enable the touch screen to select it. In auto IP mode, the oscilloscope will get
the IP address (ranging from 169.254.0.1 to 169.254.255.254) and the subnet mask
(255.255.0.0) automatically according to the current network configuration. Only
when "DHCP" is not selected or failed to be connected, can "Auto IP" be valid.
Static IP
Press IP Config Type, then rotate the multi-function knob or press IP Config
Type continuously to select "Static IP". Press down the knob to select it. You
can also enable the touch screen to select it. When this type is valid, disable DHCP
and Auto IP manually, then "IP", "SubMask", "Gateway", and "DNS" are added to the
menu. At this time, you can self-define the network parameters (e.g. IP address) of
the oscilloscope.
1. Set IP Address
The format of the IP address is nnn.nnn.nnn.nnn. The range of the first segment
(nnn) of the address is from 0 to 255 (except 127); wherein, the valid range is
from 0 to 223. The range for the other three segments is from 0 to 255. You are
recommended to ask your network administrator for an IP address available.
Press IP, and then the numeric keypad is displayed. Use the numeric keys to
input the desired IP address. This setting will be saved to the non-volatile

Rigol MSO5104 Specifications

General

Type	Tabletop
Product type	-
Bandwidth	100 MHz
Sampling rate	500000 MS/s
Channels quantity	16 channels
Minimum time base setting (per division)	3.5 ns
Display type	LCD
Display diagonal	9 \
AC input voltage	100 - 240 V
AC input frequency	45 - 440 Hz
Power consumption (max)	75 W
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Width	367 mm
