Risco Agility Installer Manual


AgilityInstallerManual
Page 1-4
Technical Specifications
ThefollowingtechnicalspecificationsareapplicablefortheAgility:
Electrical Characteristics
Power
230VAC(‐15%+10%),50Hz,50mA
Unitsconsumptions

Mainboard:Typical130mA
GSM:Standby35mA,Communication300mA
Modem:Standby20mA,Communication60mA
IPCard:90mA(Max)
Backupbattery
SealedLeadAcidBattery6V3.3Ah
InternalSirenintensity
90dBA@1m
Operatingtemperature
‐10°Cto40°C(14°Fto131°F)
Storagetemperature
‐20°Cto60°C
(‐4°Fto140°F)
Physical Characteristics
Dimension
268.5mmx219.5mmx64cm(10.57x8.64x2.52inch)
Weight(nobattery)
1.31Kg(Fullconfiguration)
GSMmodule:0.045Kg
Wireless Characteristics
RadioImmunity
AccordingtoEN50130‐4
Frequency
868.65MHz/433.92MHz


Risco Agility Specifications

General

Remote Management	Yes
Mobile App	Yes
Voice Module	Optional
Backup Battery	Yes
Two-Way Voice	Yes
Event Reporting	Yes
Remote Control	Yes
Siren Output	Yes
Type	Wireless
Communication	GSM
Compatibility	Risco accessories
Power Supply	Mains powered with battery backup
