 AgilityInstallerManual

Page 2-6

Connecting the Agility to Power Supply - Configuration A

Note:TheAgilitypanelispermanentlyconnectedtothemains.Theconnectionmustbemadeaccordingto

yourcountryʹslocalregulations.Asageneralguideline,connecttheLiveNeutralandGroundusinga

safetyapproved3‐wire18AWGpowercable(14‐mmminimumdiameterflexiblePVCcablewhich

complieswithIEC60227).ThecableshouldbebroughttotheAgilitypanelinaprotectiveplastic

conduit(diameter‐16mmminimum).

 A2‐pole16Acircuitbreakerandearthleakageprotectorshouldbeusedtodisconnectthelive

conductor,andshouldbeprovidedaspartofthebuildinginstallation.

TheAgilityispoweredbyasafetyapproved230VAC.

1.Removethepowersupplyunitcover(Figure6,1).

2.Connectthepowerwire(Safetyapproved,SVT,18AWG,0.75mm

)tothe

powerterminallocatedonthepowersupplyunit(TB1)(2,Figure6).

Note:ThepowerwireisnotsuppliedwiththeAgility.

3.DONOTconnectthecabletothewallpowersupplyatthispoint.

Ground Connection

Groundingprovidesadegreeofprotectionagainstlightningandinducedtransientsfor

anypieceofelectronicequipmentthatmay,duetolightningorstaticdischarge,

experiencepermanentorgeneralmalfunctions.Theidealgroundisconsideredto

bea

unifiedearthgroundinwhichan8‐footcopper‐cladrod,locatedclosetotheexisting

powerandtelephonegroundrods,issunkseveralfeetintotheearth.Appropriate

hardwareandclampsarethenusedtoelectricallyconnecteachoftheserodstogetherand

thentothegroundterminal ofthedevicetobeprotected.

Itmaybepossibletouseanexistingelectricalgroundonthepremisesifoneisclose

enoughtotheAgility.Whenconnectingthegroundwire,useasolid14‐gaugewire[or

larger(numericallylower)size].Keepthiswireasshortaspossibleanddonotrunitin

conduit,coilit,benditsharply,orrunitalongsideotherwiring.Ifyoumustbenditor

changeitsdirection,itshouldhavearadiusofatleast8inchesatthepointfromwhichit

isbent.Ifindoubt,youmay

wanttoenlistthehelpofalicensedelectricianinmatters

concerningsuchgrounding.



Toconnecttoground(Earth):

ConnectbetweentheAgility’sgroundterminalandanacceptableelectricalground

connectionforthelightningtransientprotectivedevicesinthisproducttobeeffective.

Important:ConnectingtogroundmustbeperformedaccordingtothelocalNationalElectricalCode.
