Risco Agility Installer Manual

AgilityInstallerManual 
Page 2-9
Connecting a telephone line to the Agility
Connectthesystemtoatelephonelineifthesystemconfigurationincludesaninternal
modem(identicalforConfigurationAandB).
1. Connecttheincomingtelephonelinetotheplug‐inCONN2jackRJ11(pins2,3)orto
plug‐inCONN3RJ31(pins4,5)(seeFigure7:Telephone
LineJacks).
2. Connectanytelephoneonthepremisestotheplug‐inCONN2jackRJ11
(pins1,4)ortoplug‐inCONN3RJ31(pins1,8)(seeFigure7:Telephone
LineJacks).
NOTE:Toensurelineseizurecapability,andcomplywithFCCpart68regulations,theequipmentmustbe
connecteddirectlytothePhonecompanylines(ʹCOʹ).WhetherconnectedviaRJ11,RJ31,theline
portmustbeconnectedtotheCOlineswithoutanyotherphonesorothertelecomequipment
betweenthem.Othertelecomequipmentcanbeconnectedonlyafter(inseries)thealarmpanel.
RJ31
RJ11
CONN2
CONN3

Figure7:TelephoneLineJacks

Risco Agility Specifications

General

Remote Management	Yes
Mobile App	Yes
Voice Module	Optional
Backup Battery	Yes
Two-Way Voice	Yes
Event Reporting	Yes
Remote Control	Yes
Siren Output	Yes
Type	Wireless
Communication	GSM
Compatibility	Risco accessories
Power Supply	Mains powered with battery backup
