Risco Agility Installer Manual

AgilityInstallerManual 
Page 3-3
TotransferthesystemconfigurationfromthePTMtotheAgilitypanel,followthis
procedure:
1. DisconnecttheflatcableandremovetheAgilitymainunitfromitswallbracket.
Note:Makesurethebatteryisinsertedintothemainunit.
MakesurethattheDefaultEnablesystemflagison
2. SetDipswitch2toON.
3. PlacethePTMontothe5‐pinPTMconnectorlocatedonthemainunitPCB.
4. AllLEDSonthemainunitwillbegintoflashsimultaneously.ThePTMLEDwill
flashquicklyduringthetransmissionofinformationtothepanel.
5. Oncetransmission
iscomplete,thepanelwillsoundaconfirmationbeep.
Note:Iftheprocedurefailsthepanelwillmake3shorterrorbeeps,andyouwillneedtodothe
procedureagain
6. DisconnectthePTMfromthemainunit.
7. ResetDipswitch2toOFF.
8. Reconnecttheflatcabletothemainunitandreplacethemainunitinitswall
bracket.

Risco Agility Specifications

General

Remote Management	Yes
Mobile App	Yes
Voice Module	Optional
Backup Battery	Yes
Two-Way Voice	Yes
Event Reporting	Yes
Remote Control	Yes
Siren Output	Yes
Type	Wireless
Communication	GSM
Compatibility	Risco accessories
Power Supply	Mains powered with battery backup
