25
The channel setting for SPOT 150 XT (Mode 1):
Channel DMX Values Functions
8 0 - 63 Light intensity from 0 to 100%
64 - 95 Shutter open
96 - 127 Strobe-effect from slow to fast (max 8 flashes/s)
128 - 139 Reset
140 - 159 Shutter closed
160 - 175 Pulse-effect in sequences with increasing speed
176 - 191 Pulse-effect in sequences with decreasing speed
192 - 223 Random strobe effect with increasing speed
224 - 255 Shutter open
If you set e.g. DIMMER =30,you will change the DMX values of the dimmer intensity from 0 to 30 with sliders INT
A or INT B.On this account you won´t be able to adjust full intensity of the light (100% intensity=64)!
For controlling the pan/tilt movement you can activate the PAN and TILT wheels :
1.by pressing <PAN/TILT> (its LED has to flash) for coarse pan/tilt movement
2.by pressing both <PAN/TILT> and <8/16 BIT> (their LEDs have to flash) for fine pan/tilt movement
For example,the screen will show :
MAKE SCENE: 001 Scene number (1-750)
SPOT 150 XT Name of assigned projector
PanH:107 PanL:041 DMX values: coarse pan, fine pan
TltH :037 TltL:255 DMX values:coarse tilt, fine tilt
5.Repeat the step 4 for all projectors in the mask.
6.Press <ENTER>.The safety question appears:
SAVE CHANGES ?
ESC/ENT
7.Press <ENTER> and the scene is recorded or <ESC> to leave this menu without saving changes.
Note 1:
By pressing <RECALL> during creating the scene you can recall previously stored scenes.
Example:
MAKE SCENE: 004 Current scene No.4
SPOT 250 XT
CH: 01-08 Sld:007
COLOR Val:064
Press <RECALL>,its LED flashes and the following screen appears:
MAKE SCENE: 004
SHOW SCENE: 004 Active scene
Use <UP>, <Down> or TILT wheel to call up previously created scenes.To return to the current scene No.4,press
<RECALL> again.
Note 2:
It is possible "to copy projectors" from previously stored scenes to the current scene:
Press <INSERT/COPY> (its LED starts flashing) and for example this screen appears:
MAKE SCENE: 010
Copy scene: 004
Select copy mask
Select projectors you wish to copy from previously created scene by pressing PROJECTOR SELECT buttons
.Select desired scene with <UP>, <Down> or TILT wheel and press <ENTER>.All DMX values of selected
projectors from desired scene are copied to the current scene.These DMX values are permanently saved after
leaving the current scene with <ENTER>.
