36
The screen shows:
INTENSITY A
Rec.: 001 Step:01
Prog.:001 Step:01
Fati:20 StTi:30 Fati=Record fade time multiplier (2) , StTi=Record step time multiplier (3)
Note:01 means 0.1 ; 99 means 9.9
Example 2 (record with 1 step only):
FADE TIME button is not active
Original record 1 STEP TIME button is not active Running record 1
Step 1 - Program 1 Step 1 - Program 1
step 1: fade time =2s step 1:fade time =4s (2 x 2s)
step time =4s step time =12s (3 x 4s)
step 2:fade time =1.5s step 2:fade time =3s (2 x 1.5s)
step time = 3s step time =9s (3 x 3s)
step 3:fade time =3s step 3:fade time =6s (2 x 3s)
step time =5s step time =15s (3 x 5s)
8.Press <RUN A> again (LED flashes) and the record starts its running (the slider INT A has to be in an upper
position of its track if Start Val=100 in "User setting") and by moving the slider INT A from a bottom possition to
an upper position of its track you can adjust the light intensity of projectors from minimum to maximum.
.If you want to pause the running record,adjust the slider to the bottom position of its track (shutters of fixtures will
be closed).After ending the record running the initial screen appears on the display.
9.Long running records can be stopped by pressing <RUN A>.
10.If you want to run the 2 records at the time,repeat the instructions 1- 8 to start the program running A.
11.Press <RECORD> to select the record running B.Repeat the steps 2-8 for slider INT B.(If you adjust the step
time and fade time multipliers, these values are used for program running A as well ).The screen shows:
INT A Rec:001- Record running A
Prog.:001 Sce.:001 Selected program and current running scene
INT B Rec: 002 Program running B
Prog.:005 Sce.:003 Selected program and current running scene
Note:The record running B "takes" the projectors assigned in the record running A and vice-versa.
Example:
assigned projectors No. active projectors in record running
Record running A 1,2,5,10,15 5,10
Record running B 1,2,15,16, 1,2,15,16
After starting the record running B,projectors No.1 and No.2 go to the program step No.2 by reason of synchronization
with the projectors No.15 and No.16 which were prepared at program step No.1 for the record running B.
The adjusted fade time and step time multipliers are used for both record running A and record running B.
For correct record running,the record running mask should be the same like the mask of the created records.
12.To stop the record running A or B, press <RUN A> or <RUN B>.
Note:By pressing the AUTO/AUDIO button (its LED flashes) the running record will folow the music´s beat.
By pressing the NEXT/+1STEP(its LED shine) button you can step the running record.
Values assigned
during record creation:
Fade time multiplier = 2
Step time multiplier = 3
Values assigned
during record creation:
Fade time multiplier = 2
Step time multiplier = 3
