Installation
20220596E 101
• Confirm the rudder ZERO position by rotating the course
knob clockwise.
The display will then show:
Set rudder
zero
Confirmed 00
Press STBD [>] to proceed to next menu item.
Compass calibration
This function will activate the automatic compass calibration
procedure.
Note ! If an optional magnetic compass is installed and connected to a
CI300X, or if a GYRO compass, or other manufacturers fluxgate
connected to a CI300X is installed, refer to the Optional Compass
Calibration Procedure accompanying the CI300X.
Before you begin the compass calibration procedure, make sure
you have enough open water around you to make a full
clockwise turn with the boat.
The calibration should be done in calm sea conditions and with
minimal wind to obtain good results. Use about 45-60 seconds
to make a full circle.
RFC compass
calibration
RFC compass
calibrating
1. Begin turning the boat to starboard.
2.
Start compass calibration by turning the course knob
clockwise. The display will flash “calibrating”.
3.
When the calibration is completed, (after having completed
approximately 1 1/4 turns), it will be confirmed by the display
reading “confirmed”.
