Robertson AP21 and AP22 Autopilots
94 20220596E
Interface Settings
The autopilot system provides a totally flexible approach to the
input of data from heading sensors and other peripheral
equipment. Identification of the type of equipment connected
to the autopilot system is performed in the Interface Menu.
When your system includes connection of external equipment
to the NMEA0183 data ports in Junction Unit or NI300X, or if
the CI300X is installed with optional compass units or an
optional analogue wind vane unit, they must be configured
under the Interface Menu. This procedure allows you to assign
an abbreviated name to identify the type of equipment that is
connected to each of the available hardware ports in the
autopilot system.
