Technical specifications
20220596E 43
3.5 RFC35 Fluxgate compass
Dimensions:.................................See Figure 3-5
Weight:.........................................0,9 kg (2,0 lbs)
Supply and output:.....................Polarity independent 2-wire supply with
superimposed pulse width modulation
Automatic Performance:
Calibration:.........................Automatically activated by control head
Gain compensation:...........Automatically adjusted continuously
Repeatability:...............................± 0.5 degrees
Roll/Pitch:.....................................± 35 degrees
Accuracy:......................................± 3 degrees after calibration
Cable supplied:............................15 m TP shielded cable
Temperature range:
Operation:...........................0 to +55 °C (+32 to + 130 °F)
Storage:................................–30 to +80 °C (–22 to +176 °F)
Environmental Protection:.........IP56
Mounting:.....................................Deck or bulkhead
Material:........................................Black ABS
Figure 3-5 RFC35 Fluxgate Compass - Dimensions
