Installation
20220596E 71
RFC35R calibration data is stored in the compass and will not be
deleted by a Master Reset in the autopilot. Offset compensation,
however, must be reset.
4.16 R3000X Remote Control installation
R3000X should be mounted in the supplied bracket that can be
fixed by four mounting screws. The unit is weather proof and
can be mounted outdoors.
TB6
J3000X/J300X JUNCTION UNIT
TB3 TB4
TB5
TB7
Stbd
Port
Gnd
Gn
Red Blu
REMOTE
TB8
TB1
TB2
R3000X
REMOTE CONTROL
Lamp
Yel
POWER PCB
Figure 4-14 R3000X connection
4.17 S35 NFU Lever installation
The unit is mounted to bulkhead or panel by two screws from
the front. The cable is connected to the junction unit according
to Figure 4-15. Interchange the port and stbd wires to the screw
terminals in the junction unit if necessary to make the direction
of the lever movement coincide with the direction of the rudder
movement.
