Installation
20220596E 107
NMEA Test
This menu item is for trouble shooting only. Do not pay
attention to the readings on the display if the system interface is
OK.
Proceed to the Master Reset menu by pressing the STBD [>]
button, or press STBY to return to normal operation.
Master Reset
INSTALLATION
Master reset
of memories
Note ! A Master Reset is part of the final test at factory and will reset the
memories to factory settings. Unless you need to clear all stored data
during the installation setup procedure, you should not perform a
Master Reset. Master reset will also clear the stored compass
calibration data, except for the RFC35R Rate compass where data are
stored in the compass.
The Master Reset needs a double confirmation to prevent an
unwanted reset. To perform a Master Reset, rotate the course
selector clockwise and observe the display; then rotate the
course selector counter clockwise.
Exit the Installation Menu by pressing STBY to return to normal
autopilot operation.
Final sea trial
After having completed all settings in the Installation Menu,
take the boat out and perform a final sea trial in open waters
with sufficient distance to other traffic.
• Steer the boat on all cardinal headings in AUTO mode.
• Start with low and medium speeds to get familiar with the
response from the autopilot.
• Try the effect of LO and HI speed settings.
• If the hardware for automatic HI/LO speed selection is
connected and configured, verify that the HI/LO transition is
occurring, and the HI/LO parameters are changing after the
