Robertson AP21 - R3000 X Remote; S35 NFU Steering Lever

Robertson AP21 and AP22 Autopilots
48 20220596E
Environmental Protection:.........IP44
Temperature range:
Operation:........................... 0 to +55 °C (+32 to +130 °F)
Storage:................................–30 to +80 °C (–22 to +176 °F)
3.11 R3000X Remote
Dimensions:.....See Figure 3-10
Weight: .............0,4 kg (0,9 lbs)
Protection.........IP56
Cable length:....7 m, shielded
Material:............Epoxy coated aluminium
Figure 3-10 R3000X - Dimensions
3.12 S35 NFU Steering Lever
Dimensions:...................See Figure 3-11
Weight:...........................1,4 kg (3,1 lbs)
incl. 10 m cable
Protection.......................IP56
Power consumption: ....6 mA
Max. inductive load:.....4A/12-24VDC
60mA/110VAC,
25mA/220VAC
Figure 3-11 S35 - Dimensions
