Manual parameter adjust
Use course dial
to adjust
parameters
Boat type:
Displayed
parameter
Rudder LO
Cont Rudd LO
Autotrim LO
Rudder lim LO
HIgh speed
Rudder HI
Cont Rudd HI
Autotrim HI
Rudder lim HI
Displacement
& Sail
Planing
0.5
1.4
40
20
0.35
1
40
20
0.3
1.4
40
20
0.2
1
40
20
Use PORT and
STBD buttons to
step through
parameters
LOw speed
Own boat
Autotune
Manual
Note ! The values in the table are factory set (default) and listed for
information only. After having performed the Autotune, the values
may differ from those listed in the table. It is recommended that you
write down the parameters "learned" by the Autotune prior to making
any adjustments.
The two most important parameters that determine the
performance of the automatic steering are Rudder and Counter
Rudder.
Rudder sets the rudder gain which is the ratio between the
commanded angle and the heading error ( P-factor).
Too little rudder
Too much rudder
Course to steer
Course to steer
