Installation
20220596E 81
COM
STBD
PORT
ENAB
AL1
AL2
SIN
COS
GND
Vref
SIN
HI
LO
NFU
WHITE
GREY
YELLOW
GREEN
BROWN
COS
MAGN. COMPANALOGUE
GYRO
MAGNETIC COMPASS
WITH CD100 COURSE
DETECTOR
FLUXGATE COMPASS
WITH SINE/COSINE
OUTPUT
DC SUPPLY
RGC10/RGC50
GYRO COMPASS
R1
R2
S1
S2
S3
WIND
VANE
CI300 COMPASS INTERFACE
ROBNET
CONNECTIONS
TB1
TB2
TB3
TB4
TB5
NOT IN USE
FOR S9
STEERING
LEVER
Figure 4-27 CI300X Interconnections
4.29 LF3000 Linear Feedback
Note ! The rod of the LF3000 is not locked in place in the cylinder. If caution
is not exercised it may slip out of its housing and end up over the side,
so be careful!
The LF3000 is a waterproof feedback unit. It has a 300 mm (11,8")
stroke and comes with a special mounting bracket which secures
the LF3000 to the cylinder of the existing outboard drive unit.
The 8,5 m (28') cable is terminated in the LFI3000 Mk2 Linear
Feedback Interface according to the wiring diagram.
