If a TCPoffset is added in the Xor Ydirections, the software will act as if an extra reach bracket is being used.
Bracket representation
Height Width Length Direction
31.5 mm 75 mm Same length asTCPoffset (X, Y) Same direction asTCPoffset (X, Y)
