4.5.SolutionMobility(WashDownand ProductionLine Shifts)
WARNING
l
Failure to properly secure and install the equipment can result in material damage and bodily injury. In
addition, note that the warranty will not cover material damagesresulting from an installation that did
not comply with the instructions found in thismanual.
l
The transport, lifting, and moving of the Palletizing Solution should be done by qualified and
authorized personnel.
Failure to do so may result in machine damage, bodily injury or death.
WARNING
Tip Over Hazard
l
The forksof the pallet truck or forklift truck must be at least 1,065 mm (42 in) in length.
l
The weight capacity of the pallet truck or forklift truck must be at least 250 kg (550 lb).
l
The Solution must be transported on a level, even and solid concrete surface using a pallet truck or
forklift truck.
l
It isthe responsibilityof the user to perform a risk assessment to account for the potential regular
repositioning of the Solution.
l
The robot should be positioned asper the moving and positioning instructions.
l
The cabling and tubing must be disconnected before transportation.
l
The Solution should be lifted aslittle aspossible, and attention must be paid to the center of gravity
to reduce the risk of tip over.
l
It isthe responsibilityof the user to determine a safe and stable course of action for the moving of the
Solution using rigging and hoisting equipment.
l
Employeesshould be qualified and properlytrained on howto use the lifting/hoisting/rigging
equipment aswell asthe Solution.
l
The Solution should be secured and stable prior to its moving and lifting
Failure to do so may result in material damage, bodily injury or death.
The Palletizing Solution can be moved and repositioned using a pallet truck or forklift truck.
There are two fork entry openings on the aisle side of the palletizer base for use with a lifting device.
67
