Robustel R3000 Quad User Guide
RT_UG_R3000 Quad_v.3.0.0 28 May, 2017 70 / 131
Confidential
destination
Protocol
Select the security protocols from “ESP” and “AH”.
 ESP: Use the ESP protocol
 AH: Use the AH protocol
ESP
Local Subnet
Enter the local subnet’s address with mask protected by IPsec, e.g. 192.168.1.0/24
Null
Remote Subnet
Enter the remote subnet’s address with mask protected by IPsec, e.g. 10.8.0.0/24
Null
The window is displayed as below when choosing “PSK” as the authentication type.
The window is displayed as below when choosing “CA” as the authentication type.
