Robustel R3000 Quad User Guide
RT_UG_R3000 Quad_v.3.0.0 28 May, 2017 71 / 131
Confidential
The window is displayed as below when choosing “xAuth PSK” as the authentication type.
The window is displayed as below when choosing “xAuth CA” as the authentication type.
IKE Settings
Item
Description
Default
Negotiation Mode
Select from “Main” and “Aggressive” for the IKE negotiation mode in phase 1.
If the IP address of one end of an IPsec tunnel is obtained dynamically, the IKE
negotiation mode must be aggressive. In this case, SAs can be established as
long as the username and password are correct.
Main
Authentication
Algorithm
Select from “MD5”, “SHA1”, “SHA2 256” or “SHA2 512” to be used in IKE
negotiation.
MD5
Encrypt Algorithm
Select from “3DES”, “AES128” and “AES256”to be used in IKE negotiation.
 3DES: Use 168-bit 3DES encryption algorithm in CBC mode
 AES128: Use 128-bit AES encryption algorithm in CBC mode
 AES256: Use 256-bit AES encryption algorithm in CBC mode
3DES
