6.9
Printer operation
Insertion of paper
Grasp the printer cover at the centre of the upper edge, lift forwards
and down onto the instrument.
Cut or fold the loose end of the paper roll diagonally and insert it
straight into the slit, pressing the “paper feed” button at the
same time.
Tear off the paper straight at the printing block.
Replace the printer cover and press the “paper feed” button. The
paper then automatically rethreads itself.
Changing the printer ribbon
Press the ribbon cassette down on the narrow side (marked “PUSH”).
When inserting the new ribbon cassette, make sure that the paper
passes between the ribbon and the body of the cassette.
