Operation with 12/24 V DC voltage
Reflotron Plus can be adapted for additional operation with 12/24 V
DC voltage so that the instrument can be operated with a car battery,
for example.
Please contact your supplier or Roche Diagnostics for further infor-
mation on this option.
When operating a Reflotron Plus adapted for use with direct current
attention should be paid to the following points:
Voltage fluctuations are permissible in the 10–30 V range.
Connect the battery to the DC socket, making sure that polarity is
correct. Reflotron Plus does not function with false polarity. It is, how-
ever, provided with reverse battery protection.
While operating Reflotron Plus with direct current it must be
disconnected from the mains.
A connecting cable (1.5 m) with the recommended Cannon
AXR-3-11 plug can also be ordered from Roche Diagnostics under
REF 1 1331582.
If you want to connect Reflotron Plus to the electrical system of your
car, please consult a car electrician.
Do not start the engine while performing a measurement.
For further technical details, R see Section 6. “Technical Information
and Notes”.
1.4
Leads of the socket
1 2
3
+ –
