16 Rockwell Automation Publication 2198-RM004C-EN-P - March 2022
Chapter 2 Replacement Considerations
Table 13 and Table 14 list power specifications and requirements for the
Kinetix 5100 drives.
Continuous output current (0-pk) 2.8 A 5.7 A 2.8 A 5.7 A 11.3 A
Peak output current (rms) 6.0 A 12.0 A 6.0 A 12.0 A 24.0 A
Peak output current (0-pk) 8.5 A 17.0 A 8.5 A 17.0 A 39.9 A
Continuous power output @ 240V nom or
120V (Voltage-doubler mode)
0.40 kW 0.80 kW 0.40 kW 0.80 kW 1.70 kW
Shunt On 390V DC
Shunt Off 375V DC
Overvoltage 430V DC
Short-circuit current rating 100,000 A (rms) symmetrical
Table 10 - Kinetix 300 Drives (Single-phase) Power Specifications (Continued)
Attribute 2097-V31PR0 2097-V31PR2 2097-V32PR0 2097-V32PR2 2097-V32PR4
Table 11 - Kinetix 300 Drives (single-phase and three-phase) Power Specifications
Attribute 2097-V33PR1 2097-V33PR3 2097-V33PR5 2097-V33PR6
AC input voltage
80…132V rms single-phase (120V nom)
80…264V rms single-phase (240V nom)
80…264V rms three-phase (240V nom)
AC input frequency 48…62 Hz
Main AC input current
Rms (nom) 120V input (voltage doubler)
Inrush (0-pk) max 120V input
Rms (nom) 120/240V input
Inrush (0-pk) max 240V input
5.0 A
68.0 A
3.0 A
136 A
8.6 A
1.15 A
5.0 A
2.3 A
15.0 A
1.15 A
8.7 A
2.3 A
24.0 A
5.65 A
13.9 A
11.3 A
Integrated AC line filter No No No No
Continuous output current (rms) 2.0 A 4.0 A 8.0 A 12.0 A
Continuous output current (0-pk) 2.8 A 5.7 A 11.3 A 17.0 A
Peak output current (rms) 6.0 A 12.0 A 24.0 A 36.0 A
Peak output current (0-pk) 8.5 A 17.0 A 39.9 A 50.9 A
Continuous power output @ 240V nom or
120V (Voltage-doubler mode)
0.50 kW 1.00 kW 2.00 kW 3.00 kW
Shunt On 390V DC
Shunt Off 375V DC
Overvoltage threshold 430V DC
Short-circuit current rating 100,000 A (rms) symmetrical
Table 12 - Kinetix 300 Drives Control Power Specification
Attribute Kinetix 300 Drives
Control power input voltage 20…26V DC
Control power input current
Nom
Inrush max (0-pk)
500 mA
30 A
