Chapter 2 Replacement Considerations
Table 13 - Kinetix 5100 Input Power Specifications (single-phase and three-phase)
Attribute 2198-E1004-ERS 2198-E1007-ERS 2198-E1015-ERS 2198-E1020-ERS
AC input voltage
95…132V rms, single-phase (120V nom)
170…253V rms, single-phase (200…230V nom)
170…253V rms, three-phase (230V nom)
AC input frequency 47…63 Hz
Main AC input current
(1)
Nom (rms) 120V input (single-phase)
Inrush max (0-pk) 120V input
Nom (rms) 230V input (single-phase)
Inrush max (0-pk) 230V input
Nom (rms) 230V input (three-phase)
max Inrush max (0-pk) 230V input
4.08 A
0.84 A
4.79 A
1.40 A
2.84 A
1.44 A
7.88 A
0.76 A
8.85 A
1.32 A
5.20 A
1.40 A
12.22 A
0.76 A
14.41 A
1.36 A
7.87 A
1.44 A
18.40 A
2.56 A
21.36 A
4.40 A
11.57 A
4.64 A
Continuous output current (rms) 2.6 A 5.1 A 7.9 A 13.4 A
Continuous output current (0-pk) 3.7 A 7.2 A 11.2 A 18.9 A
Peak output current (rms)
(2)
6.5 A 15.4 A 23.7 A 40.6 A
Peak output current (0-pk) 9.2 A 21.8 A 33.5 A 57.4 A
Continuous power output
@ 120V nom
@ 230V nom
0.20 kW
0.40 kW
0.375 kW
0.75 kW
0.75 kW
1.50 kW
1.0 kW
2.0 kW
Internal shunt on
370V @120V AC input
370V @230V AC input
Internal shunt off
Internal shunt resistor 100 Ω 100 Ω 100 Ω 20 Ω
Internal shunt power 5 W 14 W 14 W 20 W
Undervoltage threshold
70V @120V AC input
150V @230V AC input
Overvoltage threshold
410V @120V AC input
410V @230V AC input
Bus capacitance 540 µF 1680 µF 1680 µF 2160 µF
Capacitive energy absorption 6.24 J 19.40 J 19.40 J 24.95 J
Short-circuit current rating 5,000 A (rms) symmetrical
(1) Kinetix 5100 drive modules are limited to one AC mains power cycling per minute.
(2) Peak RMS current that is allowed for up to 1.8 seconds.
Table 14 - Kinetix 5100 Input Power Specifications (three-phase)
Attribute 2198-E2030-ERS 2198-E2055-ERS 2198-E2075-ERS 2198-E2150-ERS
AC input voltage 170…253V rms, three-phase (230V nom)
AC input frequency 47…63 Hz
Main AC input current
(1)
Nom (rms) 230V input (three-phase)
Inrush max (0-pk) 230V input
14.65 A
4.42 A
27.32 A
9.55 A
37.90 A
28.68 A
70.45 A
32.0 A
Continuous output current (rms) 17.9 A 41.3 A 49.0 A 78.0 A
Continuous output current (0-pk) 25.3 A 58.4 A 69.3 A 110.3 A
Peak output current (rms)
(2)
55.95 A 91.4 A 127.5 A 162.0 A
Peak output current (0-pk) 79.1 A 129.2 A 180.3 A 229.1 A
Continuous power output
@ 230V nom 3.0 kW 5.5 kW 7.5 kW 15.0 kW
Internal shunt on
370V @230V AC input
Internal shunt off
Internal shunt resistor 20 Ω — — —
Internal shunt power 20 W — — —
Undervoltage threshold 150V @230V AC input
Overvoltage threshold 410V @230V AC input
Bus capacitance 2160 µF 4100 µF 7000 µF 13,500 µF
Capacitive energy absorption 24.95 J 47.36 J 69.30 J 155.93 J
Short-circuit current rating 5,000 A (rms) symmetrical
(1) Kinetix 5100 drive modules are limited to one AC mains power cycling per minute.
(2) Peak RMS current that is allowed for up to 1.8 seconds.
