60 Rockwell Automation Publication MOTION-AT007A-EN-P - May 2020
Appendix A Kinetix and PowerFlex Drive Specifications
Peak AC input current
324…528V (rms) three-phase
33.4 A 74.3 A 148.7 A 219.2 A
Line loss ride through 20 ms
Control power DC input voltage 24V DC ±10%
Control power DC input current
(1)
(2)
0.8 A
DC
1.9 A
DC
Nominal bus output voltage 458…747V DC
Continuous output current to bus
Three-phase
10.5 A
DC
25.5 A
DC
46.9 A
DC
69.2 A
DC
Peak output current to bus
Three-phase
31.6 A
DC
70.3 A
DC
140.8 A
DC
207.6 A
DC
Peak output current duration
(3)
1.0 s1.0 s1.0 s0.1 s
Continuous output power to bus
Nom (480V rms, three-phase)
7.0 kW 17.0 kW 31.0 kW 46.0 kW
Peak output power to bus
Nom (480V rms, three-phase)
21.0 kW 46.0 kW 93.0 kW 138.0 kW
Bus overvoltage - 480V, nom AC input 832V DC
Internal shunt resistance 37.5 Ω 13.5 Ω
Internal shunt power 75 W 200 W
Shunt on
775V plus 30V x bus regulator capacity/utilization
(4)
Shunt off
765V plus 30V x bus regulator capacity/utilization
(4)
Efficiency 99%
Internal Capacitance 585 µF 780 µF 1640 µF 2050 µF
Capacitive energy absorption 129 J 172 J 362 J 453 J
Short-circuit current rating 200,000 A (rms) symmetrical
(1) All modules are limited to 1 power cycle per minute.
(2) For current values when motors include a holding brake and additional information, refer to Kinetix Servo Drives Specifications Technical Data, publication KNX-TD003
.
(3) Peak output current duration with 10% duty cycle.
(4) The shunt on and shunt off voltages increase during periods of shunting activity to promote sharing of shunt power in multi-axis configurations. Shunt utilization is equivalent to the
BusRegulatorCapacity tag in the Logix Designer application.
Table 49 - DC-bus Power Supply Specifications
Attribute 2198-P031 2198-P070 2198-P141 2198-P208
