Kinetix and PowerFlex Drive Specifications Appendix A
Table 50 - Regenerative Bus Supply Specifications
Attribute 2198-RP088 2198-RP200 2198-RP263 2198-RP312
AC input voltage
(1)
(1) Applies when DC-bus voltage regulation is enabled. If DC-bus voltage regulation is not enabled, the input voltage range is 324….528V AC. For more information on these two modes of
operation, see the Kinetix 5700 Servo Drives User Manual, publication 2198-UM002
.
324…506V rms, three-phase (480V nom)
AC input frequency 47…63 Hz
Main AC input current
(2)
324…506V (rms) three-phase
(2) All modules are limited to 1 power cycle per minute.
30.0 A 85.0 A 150.0 A 192.0 A
Max inrush (0-pk) 76.0 A 176.0 A 362.0 A 362.0 A
Peak AC input current
324…506V (rms) three-phase
75.0 A 170.0 A 225.0 A 288.9 A
Line loss ride through 20 ms
Control power DC input voltage 24V DC ±10%
Control power DC input current
(2)
(3)
(3) For current values when motors include a holding brake and additional information, refer to Kinetix Servo Drives Specifications Technical Data, publication KNX-TD003.
4.3 A
DC
5.4 A
DC
9.1 A
DC
Nominal bus output voltage 458…747V DC
Continuous output current to bus
35.3 A
DC
100.0 A
DC
176.4 A
DC
207.0 A
DC
Peak output current to bus
88.0 A
DC
200.0 A
DC
263.0 A
DC
312.0 A
DC
Peak output current duration
(4)
(4) 1.0 second peak output current duration with 10% duty cycle.
3.0 second peak output current duration with 5% duty cycle.
1.0 s/3.0 s
Continuous output power to bus
Nom (480V rms, three-phase)
24.0 kW 67.0 kW 119.0 kW 140.0 kW
Peak output power to bus
Nom (480V rms, three-phase)
60.0 kW 135.8 kW 179.7 kW 211.4 kW
Bus overvoltage - 480V, nom AC input 832V DC
Internal shunt resistance
(5)
(5) The 2198-RPxxx regenerative bus supply has no internal shunt resistor.
––
Efficiency 98%
Internal Capacitance 940 µF 2460 µF 4510 µF 5740 µF
Capacitive energy absorption 207 J 542 J 994 J 1265 J
Short-circuit current rating 200,000 A (rms) symmetrical
