Rockwell Automation Publication 750-RM004A-EN-P - April 2018 123
Enclosure Information Appendix A
Figure 33 - AC and DC Input Frame 10 PowerFlex 700S
2275.0
(89.57)
2201.8
(86.68)
597.0
(23.50)
534.7
(21.05)
2234.0
(87.95)
32.3
(1.27)
498.0
(19.61)
605.5
(23.84)
632.5*
(24.90)
635
(25.0)
2286
(90.0)
635
(25.0)
2403.5
198.5
478
655.04
454
606
(19)
(7.8)
(94.6)
(24)
(25.8)
(18)
IP54 RittalIP20 MCCIP21 Rittal
