124 Rockwell Automation Publication 750-RM004A-EN-P - April 2018
Appendix A Enclosure Information
Figure 34 - AC and DC Input Frame 11 PowerFlex 700S
797.0
(31.38)
736.0
(28.98)
32.25
(1.27)
2234.0
(87.95)
498.0
(19.61)
605.5
(23.84)
621.74*
(24.48)
DANGER!
2275.0
(89.57)
2205.0
(86.81)
2286
(90.0)
635
(25.0)
889
(35.0)
678
213
2414.5
806
(31.7)
454
655.04
(26.7)
(8.4)
(95.0)
(25.8)
(18.0)
IP54 RittalIP20 MCCIP21 Rittal
