Rockwell Automation Publication 750-RM004A-EN-P - April 2018 45
Selection Considerations Chapter 1
Analog Inputs (s) 2, bipolar, differential, 13 bit
+ sign, 0…10V DC, +/-10V DC, or
0-20ma.
(s) 1 x AI, differential, 10 bit,
0…10V DC (FOC2 temp adaption
input)
(o) 20-750 series 24V DC and
115V AC I/O modules;
1…2, depending on option module
chosen.
Bipolar, differential, 11 bit+ sign,
±10V or 4-20 mA, isolated or non-
isolated depending on option
module chosen.
Analog Outputs (s) 2, bipolar, differential, non-
isolated, 11 b + sign, +/-10V DC or
0-20ma.
(o) 20-750 series 24V DC and
115VAC I/O modules;
1…2, depending on option module
chose.
Bipolar, non-isolated, 11 bit + sign,
±10V or 0-20 mA.
Encoder Inputs 5V DC or 12V DC, quadrature,
differential with Z pulse
(o) 20-750-ENC-1 or
20-750-DENC-1, 5V DC or 12V DC,
quadrature, differential with Z pulse
Internal DC Power Supply +24V DC digital I/O, 150 mA max
+/-10V DC analog I/O, 10 mA max
+24V DC digital I/O, 200 ma max per
I/O module, 600 mA max total.
+/-10V DC analog I/O, 5 mA max
Table 14 - Communication Features
Description PowerFlex 700S, F9…F14 PowerFlex 755TL/TR Drive and
PowerFlex 755TM Common Bus
Inverter, F8…F12
Cat. No. 20D… Cat. No. 20G…
EtherNet/IP (o) single port
(o) dual-port
(s) Embedded dual-port
(o) dual-port
RS-485 HV AC (o) —
RS-485 DF1 (o) —
ControlNet (o) coax or fiber-optic (o) coax only
DeviceNet (o) (o)
LonWorks (o) —
Modbus TCP (o) —
PROFINET — (o) single or dual-port
PROFIBUS (o) (o) DPV1
CANopen (o) —
USB (o) 1203-USB (o) 1203-USB
Interbus (o) —
Remote I/O (o) —
Table 13 - User Interface (Continued)
Description PowerFlex 700S, Frames 9…14 PowerFlex 755TL/TR Drive and
PowerFlex 755TM Common Bus
Inverter, Frames 8…12
Cat. No. 20D… Cat. No. 20G…
