44 Rockwell Automation Publication 750-RM004A-EN-P - April 2018
Chapter 1 Selection Considerations
DC Bus Under Voltage (s) (s)
Fuse Blown Fault — (s)
Precharge Fault — (s)
AC Input Over Voltage Fault (s) — (s) —
Cooling Fan Fault/Alarm (s) (s)
Transient Voltage Suppressor (TVSS)
Fail Alarm
—(s)—
DC Bus Conditioner Fault (o) external device (s)
Motor Overcurrent Fault (s) (s)
Motor Overload (s) (s)
Motor Overspeed (s) (s)
Encoder Loss (s) (s)
Motor Stalled (s) —
Predictive Maintenance — (s)
Table 13 - User Interface
Description PowerFlex 700S, Frames 9…14 PowerFlex 755TL/TR Drive and
PowerFlex 755TM Common Bus
Inverter, Frames 8…12
Cat. No. 20D… Cat. No. 20G…
Local HIM (o) 20-HIM-A3, 20-HIM-A5 (o) 20-HIM-A6
Remote HIM (o) 20-HIM-C3S, 20-HIM-C5S (o) 20-HIM-C6S
DriveExplorer™ / DriveExecutive™ (s) —
Connected Components Workbench
(CCW)
(s) (s)
Studio 5000® / RSLogix 5000® (o) with communication option
module installed
(s)
Digital Inputs (s) 6, 24V DC, inputs 4…6 are
24V DC or 115VAC, input 6 default is
HW Enable
(o) 20-750 series 24V DC and
115V AC I/O modules;
3…6, depending on option module
chosen
Digital Outputs (s) 2, 24V DC open collector sinking
(s) 1, form C relay.
Relay 115V AC/24V DC, 2 A resistive
or inductive.
(o) 20-750 series 24V DC and
115V AC I/O modules;
2…3, relay or transistor depending
on option module chosen.
Relay Normally Open, 240V AC/
24V DC, 2 A resistive/general
purpose inductive.
Relay Normally Closed, 240V AC/
24V DC, 2 A resistive.
Transistor, 24V DC, 1 A max resistive.
Table 12 - Protection Features (Continued)
Description PowerFlex 700S, Frames 9…14 PowerFlex 755TL/TR Drive and
PowerFlex 755TM Common Bus
Inverter, Frames 8…12
Cat. No. 20D… Cat. No. 20G…
AC Input DC Input 755TL/TR 755TM CBI
