Selection Considerations Chapter 1
Table 30 - 650V DC Input Dimension Cross Reference
PowerFlex 700S (20D…) PowerFlex 755TM Common Bus Inverter (20G1D/E…)
Frame
Size
DC Input
without
Precharge
Catalog
Number
(1)
Enclosure
Type
Width
mm (in.)
Height
mm (in.)
Depth
(2)
mm (in.)
Frame
Size
Common Bus
Inverter
Catalog
Number
(3)
Width
(4)
mm (in.)
Height
IP21/IP54
mm (in.)
Depth
IP21/IP54
mm (in.)
F9
F9
20DJ261x…
20DJ300x…
IP21 480 (18.9) 1150 (45.3) 363 (14.3) F8 20G1ynD302… 700 (27.6) 2132 (83.9)/
2291 (90.2)
676 (26.6)/
721 (38.4)
F10 20DJ385x… IP21 Rittal
IP20 MCC
IP54 Rittal
597 (23.5)
635 (25)
606 (24)
2275 (89.6)
2286 (90)
2404 (94.6)
633 (25)
635 (25)
655 (25.8)
F8 20G1ynD361…
F10 20DJ385x… IP21 Rittal
IP20 MCC
IP54 Rittal
597 (23.5)
635 (25)
606 (24)
2275 (89.6)
2286 (90)
2404 (94.6)
633 (25)
635 (25)
655 (25.8)
F8 20G1ynD430…
F10
F10
20DJ460x…
20DJ500x…
IP21 Rittal
IP20 MCC
IP54 Rittal
597 (23.5)
635 (25)
606 (24)
2275 (89.6)
2286 (90)
2404 (94.6)
633 (25)
635 (25)
655 (25.8)
F8 20G1ynD505…
F8 20G1ynD545…
F11 20DJ590x… IP21 Rittal
IP20 MCC
IP54 Rittal
797 (31.4)
889 (35)
806 (31.7)
2275 (89.6)
2286 (90)
2415 (95)
622 (24.5)
635 (25)
655 (25.8)
F8 20G1ynD617…
F11
F11
20DJ590x…
20DJ650x…
IP21 Rittal
IP20 MCC
IP54 Rittal
797 (31.4)
889 (35)
806 (31.7)
2275 (89.6)
2286 (90)
2415 (95)
622 (24.5)
635 (25)
655 (25.8)
F8 20G1ynD710…
F11
F11
20DJ650x…
20DJ730x…
IP21 Rittal
IP20 MCC
IP54 Rittal
797 (31.4)
889 (35)
806 (31.7)
2275 (89.6)
2286 (90)
2415 (95)
622 (24.5)
635 (25)
655 (25.8)
F8 20G1ynD740…
F11 20DJ730x… IP21 Rittal
IP20 MCC
IP54 Rittal
797 (31.4)
889 (35)
806 (31.7)
2275 (89.6)
2286 (90)
2415 (95)
622 (24.5)
635 (25)
655 (25.8)
F9 20G1ynD800… 900 (35.4) 2132 (83.9)/
2291 (90.2)
676 (26.6)/
721 (38.4)
F12 20DJ820x… IP21 Rittal
IP20 MCC
IP54 Rittal
1196 (47)
1270 (50)
1205 (47.4)
2275 (89.6)
2286 (90)
2404 (94.6)
633 (24.9)
635 (25)
655 (25.8)
F12
F12
20DJ820x…
20DJ920x…
IP21 Rittal
IP20 MCC
IP54 Rittal
1196 (47)
1270 (50)
1205 (47.4)
2275 (89.6)
2286 (90)
2404 (94.6)
633 (24.9)
635 (25)
655 (25.8)
F9 20G1ynD960…
F12
F12
20DJ920x…
20DJ1K0x…
IP21 Rittal
IP20 MCC
IP54 Rittal
1196 (47)
1270 (50)
1205 (47.4)
2275 (89.6)
2286 (90)
2404 (94.6)
633 (24.9)
635 (25)
655 (25.8)
F9 20G1ynD1K0…
F13 20DJ1K1x… IP21 Rittal
IP54 Rittal
1412 (56) 2275 (89.6)
2444 (104.5)
619 (24.4)
662 (26.1)
F9 20G1ynD1K1…
F13
F13
20DJ1K1x…
20DJ1K3x…
IP21 Rittal
IP54 Rittal
IP21 Rittal
IP54 Rittal
1412 (56)
1412 (56)
1600 (63)
1600 (63)
2275 (89.6)
2444 (104.5)
2275 (89.6)
2444 (104.5)
619 (24.4)
662 (26.1)
619 (24.4)
662 (26.1)
F9 20G1ynD1K3…
F13
F13
20DJ1K3x…
20DJ1K4x…
IP21 Rittal
IP54 Rittal
1600 (63)
1600 (63)
2275 (89.6)
2444 (104.5)
619 (24.4)
662 (26.1)
F10 20G1ynD1K4… 1100 (43.3) 2132 (83.9)/
2291 (90.2)
676 (26.6)/
721 (38.4)
F13 20DJ1K4x… IP21 Rittal
IP54 Rittal
1600 (63)
1600 (63)
2275 (89.6)
2444 (104.5)
619 (24.4)
662 (26.1)
F10 20G1ynD1K6…
F10 20G1ynD2K0…
F11 20G1ynD2K6… 1500 (59) 2132 (83.9)/
2291 (90.2)
676 (26.6)/
721 (38.4)
F12 20G1ynD3K4… 1700 (66.9) 2132 (83.9)/
2291 (90.2)
676 (26.6)/
721 (38.4)
(1) <x> in catalog number is PowerFlex 700S enclosure type; catalog code A = IP21 Rittal, catalog code B = IP20 MCC, catalog code H = IP54 Rittal.
(2) The dimensions of these PowerFlex 700S units is less than the equivalent PowerFlex 755T unit. Use judgment to ensure there is sufficient space for the migration solution.
(3) <n> In catalog number is PowerFlex 755T enclosure type; catalog code 3= IP21, catalog code 4= IP54.
<
y> in catalog number is PowerFlex 755T input type; catalog code D= 755TM common bus inverter with precharge, E= 755TM common bus inverter without precharge, catalog code F= 755TL,
catalog code G= 755TR.
(4) Width dimension shows total width with power bay and control bay. The control bay is always 300 mm (11.8 in.). One control bay can serve two power bays if configured correctly. Optional wiring
bays add to total width. If optional bays are required, refer to publication 750-TD100
for dimensions and weights.
