Chapter 1 Selection Considerations
Table 35 - PowerFlex 700S Drive Options Assignment
Port Device Description
DPI 5 20-COMM-E
(1)
, 20-COMM-ER
(1)
1788-ENBT
(2)
, 20D-DL2-ENET0
(3)
(1) Frame 9 requires Expanded Cassette, frames 10…14 have standard Expanded Cassette.
(2) Requires DriveLogix option.
(3) Requires DriveLogix 5730 option.
EtherNet/IP
20-COMM-C
1788-CNC/CNCR
(2)
ControlNet
20-COMM-Q
1788-CNF/CNFR
(2)
ControlNet Fiber
20-COMM-D
1788-DNB0
(2)
DeviceNet
20-COMM-H HVAC
20-COMM-K CANopen
20-COMM-M Modbus/TCP
20-COMM-P PROFIBUS DP
20-COMM-R
(4)
(4) This item has End of Life status.
Remote I/O
20-COMM-S RS-485 DF1
0 20D-P2-SLB0 SynchLink
20D-DL2-LEB0
(5)
(5) Requires Expanded Cassette.
Logix Expansion DriveLogix™ 5730
20D-MDI-C2
(5)(6)
(6) Only one optional feedback module can be installed.
Multi-Device Interface
20D-P2-DG01
(5)(6)
DriveGuard Safe Torque Off with 2
nd
Encoder
20D-P2-ENC0
(5)(6)
2
nd
Encoder
20D-RES-A1
(5)(6)
Resolver
20D-STEG-B1
(5)(6)
Stegmann High Resolution Hiperface Encoder
Catalog code L (-T)
(5)(6)(7)
(7) Factory-installed option only.
Stegmann High Res Enc with 2
nd
Encoder
Catalog code L (-U)
(5)(6)(7)
Stegmann High Res Enc with DriveGuard Safe Torque Off
— 20-24V-AUX1 Auxiliary Control Power Supply
IMPORTANT If the existing PowerFlex 700S system uses any of the available analog I/O,
encoder input, safety modules, or Logix digital I/O you will need to supply
and configure appropriate PowerFlex 750 I/O option modules for the
replacement PowerFlex 755T product. See Chapter 2
for more details.
