D-2 PowerFlex 700S Multi-Device Interface Option Card
Supported Rotary Encoders
Please note that encoders must be ordered as "Single Ended". This will
ensure that the RS-485 channel has the proper termination network installed
at the factory.
SINCOS
®
, SINCODER
®
and LINCODER
®
are registered trademarks of Stegmann Inc.
Recommended Cables
Model Resolution Comment
SINCOS® SCS-60, SCS-70,
SCM-60, and SCM-70
512 sine cycles per revolution. SCM-60 and SCM-70 have built-in
mechanical turns counter.
SINCOS® SCS-KIT-101 and
SCM-KIT-101
1024 sine cycles per revolution. SCM-60 and SCM-70 have built-in
mechanical turns counter.
SINCOS® SRS-50, SRS-60,
SRM-50, and SRM-60
1024 sine cycles per revolution. SRM-50 and SRM-60 have built-in
mechanical turns counter.
SINCOS® SRS/M 25 1024 sine cycles per revolution SRS25 and SRM25 have built-in
mechanical turns counter. IP65
Protection Class. Size 25 square
flange mounting.
SINCOS® SRS660 1024 sine cycles per revolution Hollow-shaft up to 14 mm diameter
SINCOS® SHS-170 512 sine cycles per revolution. While the software supports this
encoder, the SHS-170 draws
excessive current and should only be
used with an external power supply.
If you are using this motor and feedback
device: Use this cable: See this wiring diagram:
Temposonics III Linear sensors with MTS part
numbers ending in 1S2G1102
Mating MTS molded extension cable for RG connector or integral P
cable
Figure 1 on page 3
Allen-Bradley 1326AB-BXXXX-21ML, and
-21MKXL motors with embedded Stegmann
rotary encoder
Allen-Bradley 1326-CECU-XXL-XXX Figure 2 on page 4
Allen-Bradley 1326AB-BXXXX-M2L, -M2KXL,
-S2L, and -S2KXL motors with embedded
Stegmann rotary encoder
Allen-Bradley 2090-CDNFDMP-SXX Figure 3 on page 4
Allen-Bradley MP-Series 460V motors with
embedded Stegmann rotary encoder
Allen-Bradley 2090-CDNFDMP-SXX or 2090-XXNFMP-SXX Figure 3 on page 4
Allen-Bradley MP-Series 230V motors with
embedded Stegmann rotary encoder
Allen-Bradley 2090-UXNFDMP-SXX or 2090-XXNFMP-SXX Figure 4 on page 4
Any other motor with external Stegmann
SHS-170 rotary encoder
Stegmann shielded twisted-pair cable with12-pin DIN style connector Figure 5 on page 5
Any other motor with external Stegmann
SCS-60, SCS-70, SCM-60 or SCM-70,
SRS-50, SRS-60, SRM-60, or SRM-60 rotary
encoder
Stegmann shielded twisted-pair cable with 12-pin DIN style connector
or 8-pin Berg style connector
Figure 5 on page 5 or
Figure 7 on page 5
Any other motor with external Stegmann
SRS-25 or SRM-25 rotary encoder
Stegmann shielded twisted-pair cable with 10-pin MS style connector Figure 6 on page 5
Any other motor with external Stegmann
SCS-Kit 101 or SCK-Kit 101 rotary encoder
Stegmann shielded twisted-pair cable with 8-pin Berg style connector Figure 7 on page 5
Any other motor with external Stegmann
SRS660 rotary encoder
Is available only with pre-attached Stegmann shielded twisted-pair
cable of various lengths
Figure 8 on page 6
