Communication Options 4-5
Figure 4.5 PowerFlex 700S Logic Status Word
Logic Bits
1514131211109876543210Status Description
x Enabled 0 = Not Enabled
1 = Enabled
x Running 0 = Not Running
1 = Running
xCommand
Direction
0 = Reverse
1 = Forward
x Actual
Direction
0 = Reverse
1 = Forward
x Accel 0 = Not Accelerating
1 = Accelerating
x Decel 0 = Not Decelerating
1 = Decelerating
x Jogging 0 = Not Jogging
1 = Jogging
x Fault 0 = No Fault
1 = Fault
xAlarm0 = No Alarm
1 = Alarm
x Flash Mode 0 = Not in Flash Mode
1 = In Flash Mode
x Run Ready 0 = Not Ready to Run
1 = Ready to Run
xAt Limit
(1)
(1)
See Parameter 304 - [Limit Status] in the PowerFlex 700S drive for a description of the limit status conditions.
0 = Not At Limit
1 = At Limit
x Tach Loss
Sw
0 = Not Tach Loss Sw
1 = Tach Loss Sw
x At Zero Spd 0 = Not At Zero Speed
1 = At Zero Speed
x At Setpt
Spd
0 = Not At Setpoint Speed
1= At Setpoint Speed
x Reserved
Table 0.B
