Frame 10 Installation 6-3
Open Type Lifting Instructions
1
2
3
Fasten the module symmetrically in at least
two (2) holes.
Use the two (2) eyebolts on the top of the unit.
Lifting the Power Module
Lifting the AC Choke
Type Weight kg (lbs.)
Power Module 120 (265)
AC Choke
CHK0520 115 (254)
