C-2 PowerFlex 700S Resolver Feedback Option Card
Allen-Bradley servo motors may be ordered with factory installed
resolvers. Table B specifies which factory installed resolvers are
supported by the 700S Resolver Feedback Option module.
Table B Compatibility with Resolvers on Allen-Bradley Motors
Motor / Resolver Type Compatible Notes
Parameter 275
[Reslvr0 Type Sel]
Setting for Phase I
Firmware 1.17
Parameter 275
[Reslvr0 Type Sel]
Setting for Phase I
Firmware 2.XX
Parameter 277
[Reslvr0 Type Sel]
Setting for Phase II
Firmware 1.XX
1326 AB 230V Primary Resolver No Receiver type resolver - not
supported
Not Supported Not Supported Not Supported
1326 AB 230V Secondary
Resolver (A-B part 118449-8)
Ye s • Secondary resolver is
geared to motor - not
intended for motor speed
/ position feedback
• Transmitter type resolver
- supported
11 - AB 118449-8 11 - Reserved 11 - Reserved
1326 AB 230V Secondary
Resolver (A-B part 129214-8)
Ye s • Secondary resolver is
geared to motor - not
intended for motor speed
/ position feedback
• Transmitter type resolver
- supported
13 - AB 129214-8 13 - Reserved 13 - Reserved
1326 AB 460V Primary Resolver Yes Transmitter type resolver -
supported
9 - AB 164982-8 9 - 1326Ax 460v 9 - 1326Ax 460v
1326 AB 460V Secondary
Resolver
Ye s • Secondary resolver is
geared to motor - not
intended for motor speed
/ position feedback
• Transmitter type resolver
- supported
13 - AB 129214-8 13 - Reserved 13 - Reserved
1326AD 230V Rare Earth
Primary Resolver
No Receiver type resolver - not
supported
Not Supported Not Supported Not Supported
1326AH 460V Explosion Proof
Motor Primary Resolver
Yes Transmitter type resolver -
supported
9 - AB 164982-8 9 - 1326Ax 460v 9 - 1326Ax 460v
1326AH 460V Explosion Proof
Motor Secondary Resolver
Ye s • Secondary resolver is
geared to motor - not
intended for motor speed
/ position feedback
• Transmitter type resolver
- supported
N/A N/A N/A
1326AS 460V Rare Earth
Primary Resolver
Yes Transmitter type resolver -
supported
9 - AB 164982-8 9 - 1326Ax 460v 9 - 1326Ax 460v
MPL 460V Primary Resolver Yes Transmitter type resolver -
supported
4 - AB 155407-8 4 - MPL 460v 4 - MPL 460v
