• Bits 10…12 “SmplRate btx” configure the sample interval for measuring
speed (see Tabl e 18
below). Increasing the encoder sample interval
improves speed measurement near zero speed. Decreasing allows the speed
control regulator to perform with high gains at high speeds.
• The remaining bits are reserved (not used).
Table 18 - FIR Filter Settings
Resolver Feedback Option
The position feedback (seen in parameter 250 [FB Opt0 Posit]) from a resolver
counts at a rate of 65,536 counts per motor revolution.
Parameter 251 [FB Opt0 Spd Fdbk] contains the speed feedback from the
resolver when connected at port 0.
Parameter 268 [Resolver0 Config] is used to configure the Resolver feedback
option card. The bits for [Resolver0 Config] are defined as follows:
• Setting bit 0 “Cable Tune” enables the cable tuning test, resetting the bit to
zero disables the test. Refer to Resolver Cable Tuning Tests
on page 138 for
more information.
• Bit 1 is reserved (not used).
• Bits 2 “Resolution 0” and 3 “Resolution 1” select the resolver resolution
(see Table 19 on page 136
). The resolution setting determines the number
of significant bits that are calculated in parameter 250 [FB Opt0 Posit]. It
does not affect the number of counts created per resolver revolution (see
Table 20 on page 136
). However, the resolution sets a limit on the
maximum tracking speed (see Table 21 on page 136
).
• Setting bit 4 “Energize” energizes the resolver, resetting the bit to zero de-
energizes the resolver.
• Bit 5 “Resolver Dir” determines the counting direction. If set to “0”,
direction is forward or up. If set to “1”, the direction is reverse or down.
Bit 12 11 10 Number of Taps
000 1
001 2
010 4
011 8
100 16
101 32
110 64
111 127
