B-2 MD60 AC Drive User Manual
B.2 Advanced Parameter Group
No. Parameter Name
Default
Value
Page
No. User Setting
A051 Digital In1 Select 4 = Preset
Frequencies
9-8
A052 Digital In2 Select 4 = Preset
Frequencies
9-8
A055 Relay Output Select 0 = Ready (Not
Faulted)
9-9
A056 Relay Output Level 0.0 9-11
A067 Accel Time 2 10.0 sec 9-11
A068 Decel Time 2 10.0 sec 9-12
A069 Internal Frequency 0.0 Hz 9-12
A070 Preset Frequency 0 0.0 Hz 9-13
A071 Preset Frequency 1 0.0 Hz 9-13
A072 Preset Frequency 2 0.0 Hz 9-13
A073 Preset Frequency 3 0.0 Hz 9-13
A078 Jog Frequency 10.0 Hz 9-13
A079 Jog Accel/Decel 10.0 sec 9-13
A080 DC Brake Time 0.0 sec 9-14
A081 DC Brake Level Amps x 0.5 9-14
A082 DB Resistor Select 0 = Disabled 9-15
A083 S Curve% 0% (Disabled) 9-15
A084 Start Boost 8 = 5.0 9-16
A088 Maximum Voltage Rated Volts 9-17
A089 Current Limit Amps x 1.8 9-17
A090 Motor OL Select 0 = No Derate 9-17
A091 PWM Frequency 4.0 kHz 9-18
A092 Auto Restart Tries 0 9-18
A093 Auto Restart Delay 1.0 sec 9-19
A094 Start At Power Up 0 = Disabled 9-19
A095 Reverse Disable 0 = Reverse
Enabled
9-19
A096 Flying Start Enable 0 = Disabled 9-20
A097 Compensation 1 = Electrical 9-20
A098 SW Current Trip 0.0 (Disabled) 9-21
A099 Process Factor
(Display Scaling)
30.0 9-21
