239
About V-LINK
Note Tx Ch
Value:
1-16
MIDI channel that will switch Edirol DV-7PR clips/palettes and will
control dissolve time.
Clip 1 Note No.
Pads 1–16 correspond to Edirol DV-7PR clips (or palettes). We
recommend that you press [PAD SETTING] to access the Pad setting
screen, and set to “Note,” using Quick Setup (p. 161) and set Clip1
Note No. to the same value as the “Pad Base Note” setting.
Value:
0(C-1)-127(G9)
Dissolve Time
Control change number that controls the dissolve time (time over
which the image switches)
Value:
OFF, CC1, CC5, CC7, CC10, CC11, CC71-74, CC91-
93, Channel Aftertouch
Ctrl Tx Ch
MIDI channel that will control the Edirol DV-7PR color Cb/Cr,
brightness, and video effect switching
Value:
1-16
Play Speed Ctrl
Range of video playback speed The three values are the playback
speeds (multiples of normal speed) at the left, center, and right
positions of the pitch bend.
Value:
0.0-1.0-2.0, 0.5-1.0-2.0, 0.0-1.0-4.0, 0.5-1.0-4.0, 0.0-1.0-
8.0, 0.5-1.0-8.0, 0.0-1.0-16.0, 0.5-1.0-16.0, 0.0-1.0-32.0,
0.5-1.0-32.0,0.0-2.0-4.0, 0.0-4.0-8.0, 0.0-8.0-16.0, 0.0-
16.0-32.0, -2.0-1.0-4.0, -6.0-1.0-8.0
Color Cb Ctrl
Control change number that controls the Cb color of the image
Color Cr Ctrl
Control change number that controls the Cr color of the image
Brightness Ctrl
Control change number that controls the brightness of the image
VFX1–4 Ctrl
Control change number that controls the video effect
* VFX2–4 are not supported by the Edirol DV-7PR.
Fade Ctrl
Control change number that controls the output fade
Value:
OFF, CC1, CC5, CC7,CC10, CC11, CC71-74, CC91-
93, Channel Aftertouch
PAD MODE
Selects whether the pads will switch clips or palettes.
Value:
CLIP, PALETT
Press [F1 (Clip)]: switch clips
Press [F2 (Palett)]: switch palettes
Local Sw
Specifies whether the internal sound generator is disconnected (OFF)
from the pads, or not (OFF).
Procedure:
Press [F5 (Local Sw)].
Value:
OFF, ON
Clip filter
(check boxes 1-32)
Clips that are checked can be switched. Enable/disable switching for
each clip
Value:
OFF, ON
Clip Reset
Turn off the image (solid black).
Procedure:
Press [F3 (Clip Reset)].
All Reset
The effect applied to the image will be reset, and brightness, color
difference, etc. will all return to the default value.
Procedure:
Press [F4 (All Reset)].
* For details on clips/palettes, dissolve time, color difference signals (Cb/
Cr), refer to the Edirol DV-7PR manual.
The Fantom-X does not support the Edirol DV-7PR’s dual
stream mode.
V-LINK Parameters
Resetting the Image
Using the Clip Filter
For example, suppose that of the rhythm set you input in the
part used for V-LINK (i.e., the part of the same number as the
Note Tx Channel), you want only the kick and snare to switch
clips. In this case, check only the clips that correspond to the
note numbers of the kick and snare. The clips will switch when
the kick or snare plays.
Fantom-X678_r_e.book 239 ページ ２００５年５月１２日 木曜日 午後４時４０分
