Roland Fantom-X6 User Manual

265
Parameter List
Rhythm Group Group (P.139)
Sample Group (P.150)
Rhythm Group Parameter
Parameter
Value
Recommended Rhy Recommended Rhythm Set USER, PRST, GM, CARD, XP-A–D
Pad Mode OFF, NOTE, PATTERN
Rhy Ptn Number Rhythm Pattern Number U001–U256, P001–P256
Rhy Ptn Velocity Rhythm Pattern Velocity REAL, 1–127
Pad Note C-1–G9
Pad Velocity REAL, 1–127
Sample Parameters
Parameter
Value
Sample Name space, A–Z, a–z, 0–9, ! ” # $ % & ’ ( ) * + , - . / : ; < = > ?
@ [ \ ] ^ _ ` { | }
Loop Mode FWD, ONE-SHOT, REV, REV-ONE
Loop Tune -50– +50
Original Key 0 (C-1) –127 (G9)
BPM tempo 5.00–300.00
Time Stretch Type TYPE01–TYPE10
Start Fine 0–255
Loop Start Fine 0–255
Loop End Fine 0–255
Fantom-X678_r_e.book 265 ページ ２００５年５月１２日 木曜日 午後４時４０分

Roland Fantom-X6 Specifications

General

Keyboard	61 keys (with velocity and channel aftertouch)
Polyphony	128 voices
Wave Memory	128 MB (16-bit linear equivalent)
User Patches	256
User Rhythm Sets	32
Preset Performances	64
User Performances	64
Arpeggiator	Yes
Preset Patches	1, 024 + 256 (GM2)
Preset Rhythm Sets	40 + 9 (GM2)
Effects	Reverb, chorus
Display	320 x 240 backlit LCD
Sequencer	16-track sequencer with 480 TPQN resolution
Sampling	Yes (up to 544MB RAM with optional DIMM)
Expansion Slots	4 SRX expansion slots
USB	USB MIDI
Weight	12.5 kg (27 lbs 9 oz)
Connectivity	MIDI, USB, line in/out, headphone, pedal
Storage	CompactFlash slot
Power Supply	AC 117 V, AC 230 V (50/60 Hz)
