34
Overview of the Fantom-X
The eight [F1]–[F8] buttons (function buttons) located below the
display execute various functions, and their operation will differ
depending on the screen. Functions will be listed in the bottom of the
screen.
fig.04-017
A single screen or window displays multiple parameters or items for
selection. To edit the setting of a parameter, move the cursor to the
value of that parameter. To select an item, move the cursor to that
item. When selected with the cursor, a parameter value or other
selection is highlighted.
fig.04-019.e
Move the cursor with the , , and (cursor buttons).
fig.04-020
: moves the cursor up.
: moves the cursor down.
: moves the cursor to the left.
: moves the cursor to the right.
If you hold down one cursor button while you also press the
cursor button for the opposite direction, the cursor will move
more rapidly in the direction of the first-pressed cursor button.
When the cursor is displayed, pressing [ENTER] will sometimes
display a list of the available choices for that parameter. This is
convenient when you want to see what your choices are. When
the list is displayed, you can also use the pads to input your
choice. (p. 35)
About the Function Buttons
Window
The somewhat smaller screens that appear temporarily on top
of the normal screens are called windows. Various types of
windows appears according to the situation. Some display lists,
others allow you to make settings, and still others ask you to
confirm an operation.
fig.04-018.e
Press [EXIT] to close the window. Some windows will close
automatically when an operation is performed.
Window
Moving the Cursor
Cursor
Fantom-X678_r_e.book 34 ページ ２００５年５月１２日 木曜日 午後４時４０分
