Using a Memory Card
The Fantom-X features a PC card slot, allowing you to use not only
PC card type memory cards, but also other types of media, such as
CompactFlash and Smart Media, via the appropriate PC card
adaptor.
Make sure that the correct side of the card is facing upward, and
insert it into the Fantom-X's PC card slot. When you need to remove
the card, press the eject button located beside the card.
fig.31a-001
Patches, rhythm sets, performances, samples, and song data can be
written to the card. For details on the writing procedure, refer to the
explanation for the corresponding parameters.
The Fantom-X provides a PC card protector to prevent theft of the
memory card. To install the PC card protector, use the following
procedure.
1. Use a screwdriver to remove both of the screws from the
bottom side of the PC CARD slot.
2. Insert the memory card into the PC CARD card slot.
3. Use the screws to fasten the PC card protector as shown
below.
fig.31a-002
Before Using the Memory
Card
Writing data to the card
Eject
memory
card
Installing the PC Card
Protector
PC card protector
Memory card
Fantom-X Rear Panel
Fantom-X678_r_e.book 248 ページ ２００５年５月１２日 木曜日 午後４時４０分

Roland Fantom-X6 Specifications

General

Keyboard	61 keys (with velocity and channel aftertouch)
Polyphony	128 voices
Wave Memory	128 MB (16-bit linear equivalent)
User Patches	256
User Rhythm Sets	32
Preset Performances	64
User Performances	64
Arpeggiator	Yes
Preset Patches	1, 024 + 256 (GM2)
Preset Rhythm Sets	40 + 9 (GM2)
Effects	Reverb, chorus
Display	320 x 240 backlit LCD
Sequencer	16-track sequencer with 480 TPQN resolution
Sampling	Yes (up to 544MB RAM with optional DIMM)
Expansion Slots	4 SRX expansion slots
USB	USB MIDI
Weight	12.5 kg (27 lbs 9 oz)
Connectivity	MIDI, USB, line in/out, headphone, pedal
Storage	CompactFlash slot
Power Supply	AC 117 V, AC 230 V (50/60 Hz)
