Parameter List
Parameter Value Explanation
Bend Range Up
0–48
[semitone]
Species in semitones the amount of change
that occurs when you press the far right end
of the ribbon controller.
For example, if this parameter is set to “12,
the pitch will rise one octave when the
pitch bend lever is moved to the right-most
position.
Bend Range Down
0–48
[semitone]
Species in semitone units the amount of
change that occurs when you press the far
left end of the ribbon controller.
For example if this is set to “48” and you move
the pitch bend lever all the way to the left,
the pitch will fall 4 octaves.
Bend Mode
NORMAL
The pitch bend lever works in the
conventional way.
CATCH+LAST
The ribbon controller aects only the last-
sounded note.
If you play a note while the ribbon controller
is already moved, that note sounds at its
normal pitch (as though the controller were
in the center).
The pitch starts changing only after the
controller passes through the center position.
Bend Range Fine Up 0–100 [cent]
Finely adjusts the degree of pitch change in
one-cent units when the Pitch Bend lever is
moved to the right.
Bend Range Fine
Down
0–100 [cent]
Finely adjusts the degree of pitch change in
one-cent units when the Pitch Bend lever is
moved to the left.
STRUCTURE
Structure lets you sound two partials as a set.
You can create a wide range of sounds by using partial 2 or 4 (the
modulator) to modulate partial 1 or 3 (the carrier).
Since the Structure uses two partials as a pair, it provides parameters
that are used in common by the carrier and modulator.
For the following parameters, only the partial settings of the carrier are
valid (the settings of the modulator are ignored).
KEYBOARD
5
Keyboard Range Lower
5
Keyboard Range Upper
5
Keyboard Fade Width Lower
5
Keyboard Fade Width Upper
5
Velocity Range Lower
5
Velocity Range Upper
5
Velocity Fade Width Lower
5
Velocity Fade Width Upper
SWITCH
5
Partial Switch
OSC
5
Delay Mode (note)
5
Delay Mode
5
Delay Time Sync
5
Delay Time (note)
5
Delay Time
CONTROL
5
Envelope Mode
5
Receive Hold-1
5
Redamper Switch
5
Damper Free Note
5
MATRIX CONTROL
5
Destination: PMT
5
Destination: CROSS-MOD
Parameter Value Explanation
Structure1-2
The sound of partial 1 is modulated by partial 2.
OFF OFF
SYNC
Implements the oscillator sync function that
is provided by an analog synthesizer.
The partial 1 oscillator is reset at intervals of
partial 2’s pitch cycle. This is eective only if
OSC Type is VirtualAnalog or PCM-Sync.
RING
Implements the ring modulator function that
is provided by an analog synthesizer.
The output sound of partial 2 is multiplied
with partial 1.
XMOD, XMOD2
Implements the cross modulation function
that is provided by an analog synthesizer.
The output sound of partial 2 is applied as
the pitch of partial 1.
XMOD2 is available only when Partial 1 and 3
are OSC Type “VA.
Structure3-4
The output sound of partial 3 is modulated by partial 4.
OFF OFF
SYNC
Implements the oscillator sync function that
is provided by an analog synthesizer.
The partial 3 oscillator is reset at intervals of
partial 4’s pitch cycle. This is eective only if
OSC Type is VirtualAnalog or PCM-Sync.
RING
Implements the ring modulator function that
is provided by an analog synthesizer.
The output sound of partial 4 is multiplied
with partial 3.
XMOD, XMOD2
Implements the cross modulation function
that is provided by an analog synthesizer.
The output sound of partial 4 is applied as
the pitch of partial 3.
XMOD2 is available only when Partial 1 and 3
are OSC Type “VA.
RING1-2 Level 0–127 RING level when Structure1-2 is RING.
RING3-4 Level 0–127 RING level when Structure3-4 is RING.
RING OSC1 Level 0–127
Eective when Structure1-2 is RING. Sets the
partial 1 OSC level.
RING OSC2 Level 0–127
Eective when Structure1-2 is RING. Sets the
partial 2 OSC level.
RING OSC3 Level 0–127
Eective when Structure3-4 is RING. Sets the
partial 3 OSC level.
RING OSC4 Level 0–127
Eective when Structure3-4 is RING. Sets the
partial 4 OSC level.
XMOD 1-2 Depth 0–9600 [cent]
Cross Modulation Depth when Structure1-2 is
XMOD.
XMOD 3-4 Depth 0–9600 [cent]
Cross Modulation Depth when Structure3-4 is
XMOD.
XMOD2
1-2 Depth
0–127
Cross Modulation Depth when Structure1-2 is
XMOD2.
XMOD2
3-4 Depth
0–127
Cross Modulation Depth when Structure3-4 is
XMOD2.
CrossMod OSC1
Level
0–127
Eective when Structure1-2 is XMOD/
XMOD2. Sets the partial 1 OSC level.
CrossMod OSC2
Level
0–127
Eective when Structure1-2 is XMOD/
XMOD2. Sets the partial 2 OSC level.
CrossMod OSC3
Level
0–127
Eective when Structure3-4 is XMOD/
XMOD2. Sets the partial 3 OSC level.
CrossMod OSC4
Level
0–127
Eective when Structure3-4 is XMOD/
XMOD2. Sets the partial 4 OSC level.
OSC MOD COM
Parameter Value Explanation
Partial Phase Lock OFF, ON
This is available if OSC Type is VA”; it locks
the waveform phase between partials. It is
eective to use this with XMOD2.
