Rosemount 3095 - Page 85

A-3
HART Communicator
TABLE A-1. HART Fast Key Sequences for the Level Controller.
Function
HART Communicator
Fast Key Sequences
Function
HART Communicator
Fast Key Sequences
ABC Static Error 6, 2, 1, 9 LV Damping 6, 1, 1, 5
AO Alrm typ 6, 4, 3, 8 LV LRL 6, 1, 1, 4, 5
Accept Auto-Tune 6, 2, 4, 5 LV LRV 6, 1, 1, 4, 2
Actual Mode 6, 2, 3, 2 LV Trim 6, 1, 1, 6
Adapt Bias Ctl 6, 2, 1, 8 LV URL 6, 1, 1, 4, 4
Alpha 6, 2, 4, 3, 3 LV URV 6, 1, 1, 4, 1
Analog Signal 5 LV Unit 6, 1, 1, 3
Balance Time 6, 2, 1, 7 Level 1 or 6, 1, 1, 2
Bias 6, 2, 1, 6 Loop test 6, 3, 5
Burst Mode 6, 4, 1, 4, 2 Manual Rate Limit 6, 2, 5, 2
Burst option 6, 4, 1, 4, 1 Manual 4 or 6, 2, 5, 1
Cntl Action 6, 2, 1, 1, 2 Manufacturer 6, 4, 3, 1
Cntl Out 6, 2, 5, 1 Message 6, 4, 3, 4
Cntl Type 4 or 6, 2, 1, 1, 1 Meter 6, 4, 5, 1
Cycles 6, 2, 4, 3, 8 Num req preams 6, 4, 1, 2
D/A trim 6, 3, 1 Num resp preams 6, 4, 1, 3
D: Rate 6, 2, 1, 4 O ring matl 6, 4, 2, 6
DP Damping 6, 1, 2, 3 Out HI Lim 6, 2, 1, 1, 3
DP LSL 6, 1, 2, 6 Out LO Lim 6, 2, 1, 1, 4
DP Sensor Trim 6, 1, 2, 4 Overshoot 6, 2, 4, 3, 4
DP Sensor Trim 6, 3, 4, 2 P: Gain 6, 2, 1, 2
DP USL 6, 1, 2, 5 PT Damping 6, 1, 3, 4
DP Unit 6, 1, 2, 2 PT LSL 6, 1, 3, 7
DP 6, 1, 2, 1 PT Sensor Trim 6, 1, 3, 5
Date 6, 4, 3, 5 PT USL 6, 1, 3, 6
Density 6, 1, 1, 1, 2 PT Unit 6, 1, 3, 3
Deriv Fltr 6, 2, 1, 5 PT 6, 1, 3, 2
Descriptor 6, 4, 3, 3 Perform Auto-Tune 6, 2, 4, 4
Density Unit 6, 1, 1, 1, 1 Power-up Out 6, 2, 3, 6
Drain vent matl 6, 4, 2, 5 Process Gain 6, 2, 4, 9
Factory Trim 6, 3, 3 RS fill fluid 6, 4, 2, 8
Fill fluid 6, 4, 2, 2 RS isoltr matl 6, 4, 2, 9
Final asmbly num 6, 4, 3, 6 RS type 6, 4, 2, 7
Flange type 6, 4, 2, 4 Reset 6, 3, 7
Fld dev rev 6, 4, 4, 2 RTD 6, 1, 3, 1
Flnge matl 6, 4, 2, 3 SP Hi Lim 6, 2, 2, 4
Gravity 6, 1, 1, 1, 3 SP Lo Lim 6, 2, 2, 5
Hardware rev 6, 4, 4, 4 SP Rate Limits 6, 2, 2, 3
I: Reset 6, 2, 1, 3 SP Track 6, 2, 2, 6
Isoltr matl 6, 4, 2, 1 Scaled D/A trim 6, 3, 2
LOI Enable 6, 4, 5, 2 Setpoint 2 or 6, 2, 2, 1
LOI Display Slot 2 6, 4, 5, 3 Setpoint Active 6, 2, 2, 2
LOI Display Slot 3 6, 4, 5, 4 Shed Action 6, 2, 3, 3
LOI Display Slot 4 6, 4, 5, 5 Shed Return 6, 2, 3, 5
LOI DP Unit 6, 4, 5, 7 Shed Out 6, 2, 3, 4
LOI Level Unit 6, 4, 5, 6 Snsr Module hw rev 6, 4, 4, 6
LOI PT Unit 6, 4, 5, 8 Snsr Module sw rev 6, 4, 4, 5
