Hazardous Area Oxymitter 5000
Signals
Digital Output FOUNDATION fieldbus compatible
Logic I/O Two-terminal logic contact configurable as either an
alarm output or as a bi-directional calibration
handshake signal to IMPS 4000 or SPS 4001B,
self-powered (+5 V) in series with 340 ohms
Conduit ports — 3/4 in.-14 NPT (for Foundation
fieldbus and logic I/O signal lines)
Power Requirements:
Probe Heater 175 W nominal
Electronics 10 W nominal
Maximum 500 W
Hazardous Area Oxymitter Certifications
Hazardous Area Oxymitter 5000 with Integral Electronics
KEMA/ATEX II 2 G EEx d IIB+H2 T6 (Elect Comp) / T2 (Probe)
CSA
Class I, Division 1, Groups B, C, D T2
Class I, Zone 1, Ex d IIB+H2 T2
Class I, Zone 1, AEx d IIB+H2 T2
FM
Class I, Division 1, Groups B, C, D T2
Class I, Zone 1, AEx d IIB+H2 T2
Hazardous Area Oxymitter with Remote Electronics
KEMA/ATEX
II 2 G EEx d IIB+H2 T2 (Remote Probe)
II 2 G EEx de IIB+H2 T6 (Remote Electronics)
CSA
Class I, Zone 1, Ex d IIB+H2 T2 (Remote Probe)
Class I, Zone 1, Ex de IIB+H2 T6 (Remote Electronics)
Class I, Zone 1, AEx d IIB+H2 T2 (Remote Probe)
Class I, Zone 1, AEx de IIB+H2 T6 (Remote
Electronics)
FM
Class I, Zone 1, AEx d IIB+H2 T2 (Remote Probe)
Class I, Zone 1, AEx de IIB+H2 T6 (Remote
Electronics)
Hazardous Area Oxymitter Specifications
