Hazardous Area Oxymitter 5000
1-16
Instruction Manual
IM-106-350C, Rev 2.2
July 2008
Table 1-1. Product Matrix
OXT5C Oxymitter 5000 Explosion Proof with FOUNDATION fieldbus- In Situ Oxygen Transmitter
Explosion Proof Oxygen Transmitter - Instruction Book
Code Sensing Probe Type with Flame Arrestor
1 Ceramic Diffusion Element Probe (ANSI 3 in. 150 lb bolt cirlce)
2 Snubber Diffusion Element (ANSI 3 in. 150 lb bolt cirlce)
3 Ceramic Diffusion Element Probe (DIN 2527) - 1/4 in. Tube Fittings
4 Snubber Diffusion Element (DIN 2527) - 1/4 in. Tube Fittings
7 Ceramic Diffusion Element Probe (ANSI 3 in. 300 lb bolt cirlce)
8 Ceramic Diffusion Element Probe (ANSI 4 in. 300 lb bolt cirlce)
Code Probe Assembly
0 18 in. (457 mm) Probe
2 18 in. (457 mm) Probe with Abrasive Shield
(1)
3 3 ft (0,91 m) Probe
4 3 ft (0,91 m) Probe with Abrasive Shield
(1)
5 6 ft (1,83 m) Probe
6 6 ft (1,83 m) Probe with Abrasive Shield
(1)
Code Mounting Adaptor- Stack Side
0 No Adaptor Plate ("0" must be chosen under "Mounting Adaptor - Probe Side" below)
1 New Installation - Square weld plate with studs
2 Model 218 Mounting Plate (with Model 218 Shield Removed)
3 Competitor’s Mount
Code Mounting Adaptor-Probe Side
0 No Adaptor Plate
1 Probe Only (ANSI)
2 New Bypass or New Abrasive Shield (ANSI)
4 Probe Only (DIN)
5 New Bypass or New Abrasive Shield (DIN)
Code Electronic Housing - NEMA 4X, IP66
12 FOUNDATION fieldbus electronics, mounted integral to probe, transient
protected termination ATEX EExdllB+H2T2
14 FOUNDATION fieldbus electronics, mounted remotely, transient protected
termination; requires cable ATEX EExdllB+H2T2
22 FOUNDATION fieldbus electronics, mounted integral to probe, transient
protected termination Class I Div. I, Group B,C,D
24 FOUNDATION fieldbus electronics, mounted remotely, transient protected
termination; requires cable Class I Div. I, Group B,C,D
OXT5C 3 3 1 1 14 Example
