Instruction Manual
IM-106-350C, Rev 2.2
July 2008
1-17
Hazardous Area Oxymitter 5000
NOTES:
High Sulfur Service:
High sulfur cell can be selected for any probe; add a line item note to your purchase order requesing the high sulfur ZrO2 cell in place of the standard ZrO2 cell.
(1)
Recommended uses: High velocity particulates in flue stream, installation within 10ft (3,5 m) of soot blowers or heavy salt cake buildup. Applications:
Pulverized coal, recovery boilers, lime kiln.
(2)
Where possible, specify ANSI or DIN designation; otherwise, provide details of the existing mounting plate as follows:
(3)
Startup, calibration, and operation can be implemented using the standard membrane keypad. Remote access and additional functionality available via
Fieldbus Communications (DeltaV).
Cont’d
Code Operator Interface
(3)
1 Membrane Keypad - Fieldbus, Blind Cover
2 Membrane Keypad - Fieldbus, Window Cover
3 Gas Florescent LOI, Fieldbus, English only, Window Cover
Code Language
1 English
2 German
3 French
4 Spanish
5 Italian
Code Termination Filtering
00 No Option - Specified as part of Electronic Housing
Code Calibration Accessories
00 No Hardware
01 Cal/Ref Flowmeters and Reference Pressure Regulator
02 Autocalibration Systems - order by seperate part number (for safe areas only)
Code Hazardous Area Approval
00 certification selected elsewhere
Code Control Suite Functionality
00 Basic Control Suite
01 Deduct Basic Control Suite
Code Electronics to Probe Cable
00 No Cable, Integral Electronics
10 20 ft (6 m) Cable - Remote Electronics
11 40 ft (12 m) Cable - Remote Electronics
12 60 ft (18 m) Cable - Remote Electronics
13 80 ft (24 m) Cable - Remote Electronics
14 100 ft (30 m) Cable - Remote Electronics
15 150 ft (45 m) Cable - Remote Electronics
16 200 ft (61 m) Cable - Remote Electronics
Cont’d 1 3 00 01 00 00 00 Example
Plate with studs Bolt circle diameter, number, and arrangement of studs; stud thread; and stud height above mounting plate.
Plate without studs Bolt circle diameter, number, and arrangement of holes; thread; and depth of stud mounting plate with accessories.
