Hazardous Area Oxymitter 5000
2-6
Instruction Manual
IM-106-350C, Rev 2.2
July 2008
Figure 2-4. Hazardous Area
Oxymitter 5000 Mounting Plate
Dimensions
22.5
o
B
C
8 Threadedholes
equallyspaced
onDDiaB.C.
AbrasiveShield
FlangeO.D.
A
A
Table5.MountingPlateDimensionsfor
Hazardous AreaOxymitter5000
Dimensions
mm
(in.)
"A"
"B”
StudSize
“C"
DiaB.C.
ANSI
197
(7.75)
0.625-11
152.4
(6.00)
DIN
216
(8.50)
M16x2
170.0
(6.69)
MOUNTINGPLATEFOR
HAZARDOUS AREA OXYMITTER5000
WITH ABRASIVESHIELD
MOUNTINGPLATEFOR
HAZARDOUS AREA OXYMITTER5000
Crosshatchedareain
4cornersmaybeused
toprovideadditional
holesforfieldbolting
ofplatetooutside
wallsurface.
4Studs,
Lockwashersand
Nutsequally
spacedonCDia
B.C.
A
82.6
(3.25)Dia
B
38740073
C
MOUNTINGPLATEOUTLINE
Note:Dimensionsareinmillimeters
withinchesinparentheses.
Table6.MountingPlateDimensionsforHazardous Area
Oxymitter5000with AbrasiveShield
DIN
235
(9.25)
100
(3.94)
190
(7.48)
M20x2.5
ANSI
229
(9.00)
121
(4.75)
191
(7.50)
0.625-11
Dimensions
mm
(in.)
"A"
"B"
Dia
"D"
DiaB.C.
"C"
Thread
