Rosemount Oxymitter 5000 - Page 39

Instruction Manual
IM-106-350C, Rev 2.2
July 2008
2-7
Hazardous Area Oxymitter 5000
Figure 2-5. Hazardous Area
Oxymitter 5000 Mounting Plate
Installation
13(0.50)
95(3.75)
MinimumDia
HoleinWall
StackorDuct
MetalWall
Mountingholes
shownrotated45
o
Weldorboltmountingplatetometalwall
ofstackorduct;Jointmustbeairtight.
13 0.50( )
114(4.50)
O.D.Ref
Pipe4.00in.Sched40Pipe
Sleeve(NotbyEmerson
ProcessManagement)
lengthbyCustomer
Masonry
stackwall
OutsideWall
Surface
JointMust
be Air Tight
MountingHoles
ShownRotated45
of TruePosition
o
FieldWeldPipe
toMountingPlate
BoltMountingPlateto
OutsideWallSurface
82.5(3.25)
MinimumDia
HoleinWall
StackorDuct
MetalWall
Weldorboltmountingplateto
metalwallofstackorduct.
Jointmustbeairtight.
Fieldweldpipe
toMountingPlate
102(4.0)
O.D.Ref
Pipe3.5in.Sched40Pipe
Sleeve(Notby
)
lengthbyCustomer
Emerson
ProcessManagement
Masonry
stackwall
OutsideWall
Surface
JointMust
be Air Tight
BoltMountingPlateto
OutsideWallSurface
38740005
INSTALLATIONFORMASONRY
WALL STACKCONSTRUCTION
INSTALLATIONFORMETAL WALL
STACKORDUCTCONSTRUCTION
Notes:
1.Dimensionsareinmillimeterswith
inchesinparentheses.
ABRASIVESHIELDMOUNTING
PROBEMOUNTING
outoftrueposition
out
2. Allmasonrystackworkandjointsexceptadaptor
platearenotfurnishedbyRosemont Analytical.
