HIGHLIGHTS OF CHANGES (CONTINUED)
Effective September 2006 Rev 2.0
(Continued)
Effective January 2007 Rev 2.1
Page Summary
Page 4-1 thru 4-6 Added Section 4, Configuration of Hazardous Area Oxymitter 5000 with LOI.
Page 5-1 thru 5-4 Pages 3-6 thru 3-8 in Section 3, Startup and Operation of Rev 1.4 was moved to Section 5,
Startup and Operation of Oxymitter 5000 with Membrane Keypad.
Page 6-1 thru 6-10 Added Section 6, Startup and Operation of Hazardous Area Oxymitter 5000 with LOI.
Page 7-1 Added body text under Overview.
Page 7-2 Added Figure 7-1, O
2
Sensor mV Reading vs. % O
2
at 736°C (Reference Air, 20.9% O
2
).
Page 7-4 Added Figure 7-2, Diagnostic LEDs.
Page 7-7 thru 7-21 Added the LOI in Figures 7-3 thru 7-17 with descriptive text to accompany each figure.
Page 7-22 and 7-23 Added text and Figure 7-18, Probe Leakage Paths.
Page 8-0 Moved the "Calibration Record for Rosemount Analytical in Situ O
2
Probe", from the back
of the section to the front.
Page 8-6 and 8-7 Added information under the Calibration with LOI heading.
Page 8-7 Removed information regarding LED Status Indicators and Table 4-1, Diagnostic/Unit
Alarms from Rev 1.4.
Page 8-8 thru 8-23 Updated procedural steps throughout section.
Page 8-9 Added step 3 under Entire Replacement of Electronics (with Housing). Removed Figure
4-4, Terminal Block from Rev 1.4.
page 8-10 Updated Figure 8-3, Hazardous Area Oxymitter 5000 with Integral Electronics - Exploded
View, to show the LOI module and Window Cover.
Page 8-11 Added Figure 8-4, Hazardous Area Oxymitter 5000 with Remote Electronics - Exploded
View.
Page 8-16 Added third Warning.
Page A-1 thru A-22 Moved Safety Instructions P-3 thru P-12 from the preface in Rev 1.4 to Appendix A in Rev
2.0.
Page B-1 Moved Section 10, Return of Material from Rev 1.4 to Appendix B in Rev 2.0.
Page C-1 thru C-6 Moved Appendix A to Appendix C in Rev 2.0.
Page D-1 thru D-10 Moved Appendix B to Appendix D in Rev 2.0.
Page E-1 Moved Appendix C to Appendix E in Rev 2.0.
Page Summary
General Revised reference air specifications to read 0.25 l/min (0.5 scfh) throughout the manual.
Page 7-1 thru 7-6 Added section 7.
Page 8-22 Added the paragraph and procedural steps after 'Heater Not Open, but Unable to Reach
736°C Setpoint.'
Page 11-1 Added Model 375 Handheld Communicator information.
